Dimension & Diagram

Part No.Naming system

Part No.	L*W*H（mm）	Emitting color	Package Description	λD(nm)	Datasheet
KL02821WDBASR	15.00×10.00×6.00	Super red	Black Face, White Segment, common cathode	620-630nm
KL02821WDBO	15.00×10.00×6.00	Orange	Black Face, White Segment, common cathode	600-610nm
KL02821WDBAY	15.00×10.00×6.00	Yellow	Black Face, White Segment, common cathode	585-595nm
KL02821WDBASG	15.00×10.00×6.00	Super green	Black Face, White Segment, common cathode	568-573nm
KL02821WDBAPG	15.00×10.00×6.00	Pure green	Black Face, White Segment, common cathode	515-525nm
KL02821WDBAB	15.00×10.00×6.00	Blue	Black Face, White Segment, common cathode	450-470nm
KL02821WDBAW	15.00×10.00×6.00	White	Black Face, White Segment, common cathode	/
